LY -72HLM Half Cut Double Glass Mono Solar Panel
Request a Quote
Features
- 144 half-cells monocrystalline module
- Front tempered glass
- Back glass
- Size: 2094*1038*35mm
- Max. Module efficiency: 20.4%
- Aluminum alloy frame
Description
This 144 half-cell double glass monocrystalline photovoltaic module is efficient and cost-effective largely thanks to its high performance double sided PERC cells, delivering higher electricity generation. The front panel uses extra clear tempered glass, which has very high solar transmittance for improved solar energy conversion, consistent performance and durability. Its rear uses TPT back sheet, as well as PVB film reinforcement on both sides, so that it can handle a higher pressure load and promote efficiency.
Technical Parameters
| Mechanical Parameters | |
| Length | 2094mm |
| Width | 1038mm |
| Weight | 22.7kg |
| Thickness | 35mm |
| Area | 2.174m2 |
| Individual leadwire | 4mm2 |
| Connectors | MC4/MC4 equivalent |
| Junction Box | IP68 |
| Cell type | Monocrystalline cell |
| Frame material | Aluminum alloy |
| Front glass | Extra clear tempered glass，3.2mm |
| Encapsulation | PVB |
| Load rating | Static: 5400Pa Wind: 2400Pa |
Module numbers and ratings at standard test conditions(1000W/m2, AM 1.5, 25°C)
| Nominal values | 440 | 445 | 450 | |
| Nominal power (-0/ 5W) | PMPP (W) | 440 | 445 | 450 |
| Voltage at Pmax | VMPP (V) | 41 | 41.2 | 41.26 |
| Current at Pmax | IMPP (A) | 10.73 | 10.8 | 10.91 |
| Open circuit voltage | VOC (V) | 49.2 | 49.4 | 49.85 |
| Short circuit current | ISC (A) | 11.45 | 11.52 | 12.24 |
| Module efficiency | % | 20.2 | 20.5 | 20.7 |
| Operation temperature | ℃ | -40~ 85 | -40~ 85 | -40~ 85 |
| Maximum system voltage | VSYS (V) | 1500 | 1500 | 1500 |
| Maximum series fuse | ICF (A) | 20A | 20A | 20A |
