High Speed Carton Equipment Manufacturer

Description
The high speed folding and gluing line’s 1100 type folding carton machine is controlled by a servo motor. With the extended crash lock and 3m pre-folder sections, its maximum blank width reaches 1100mm and the processing speed is 500m/min. It is used to produce various boxes with a length of 17.81m and a width of 1.9m, including straight-line boxes, crash-lock bottom boxes, 4 and 6 corners boxes and other box types.

Application

The SMARTFOLD Ultra 1100 – PC is used to produce straight-line boxes, crash-lock bottom boxes, double-wall boxes and other box types.

The SMARTFOLD Ultra 1100 – SL is used to manufacture straight-line boxes, crash-lock bottom boxes, double-wall boxes, 4 and 6 corners boxes and other box types.

Produced box type
  • straight-line box A: 195 - 1100 mm
    B: 100 - 1200 mm
    E: 90 - 540 mm
  • crash-lock bottom box A: 195 - 1100 mm
    B: 110 - 1200 mm
    E: 90 - 540 mm
  • double-wall box A: 240 - 1100 mm
    B: 100 - 1200 mm
    D: 30 - 150 mm
    E: 100 - 960 mm
  • 4-corner box A: 160 - 1100 mm
    B: 140 - 1200 mm
    H: 25 - 150 mm
  • 4-corner box with lid A: 270 - 1100 mm
    B: 140 - 1100 mm
    H: 25 - 150 mm
  • 6-corner box A: 270 - 1100 mm
    B: 140 - 1100 mm
    H: 25 - 150 mm
Processed materials
  • Carton board
  • Corrugated board
Parameters
Processed materials
Max. Carton board 800 g/m²
Corrugated flute type N, E & F
Capacity
Max. speed 500 m/min
Inching speed 30 m/min
Max. Thickness of folded box 20 mm
Max. Blank width 1100 mm
Total length of pressure conveyor section 5.5 m
Effective pressure conveying length 3.1 m
Lower belt width 25mm
Outer belt width 30mm
Feeding conveyor belt number 8 pieces
Feeding belt width 30mm
Size and Weight
Item PC SL
Length 17.81 m 17.81 m
Width 1.9 m 1.9 m
Height 1.9 m 1.9 m
Weight 11.3 Ton 11.5 Ton
Installation
Item PC SL
Electrical connected load 66 kW 66 kW
Compressed air 6 bar 6 bar
Air compressor capacity 10 m³/h 10 m³/h
Air tank capacity 60 L 60 L
folding carton gluing system components
  • Feeder section
  • Register table
  • Pre-folding section
  • Multi-function section
  • Gluing unit
  • Folding and closing section
  • Trombone section
  • Press section
  • Back-folding device
