Application
The YCZX60 wrap around case packer's production capacity is 60 cases/min, which is suitable for carton packaging on bottle (can) production lines for beer, other beverages, bottled water, medicine, food, and more. With this packaging method, users can save about 1/5 of the cost of packaging materials when compared to traditional packaging methods.

Technical parameters
Equipment model YCZX60
Machine dimension L12380mm *W3820mm *H2628mm
Formed carton dimension 550 < L+W+H < 1000
Production capacity 60 cases/min
Working voltage/power 380V, 50Hz/22KW three phase
Hot melt adhesive solidify time 1.5~2S
Working air pressure 0.6~0.8Mpa
Machine weight 11000kg
Bottle height 110~340mm
Bottle diameter ф50~180mm
Features
  • Using internationally known hot melt adhesive equipment, operation is easy and the equipment is durable.
  • Advanced technology, including reasonable mechanical structure of linear bottle and board feeding, reliable pneumatic device and advanced electric-control technology.
