AC Spot Welding, 63KVA Resistance Welder

AC Spot Welding, 63KVA Resistance Welder
AC Spot Welding, 63KVA Resistance Welder
AC Spot Welding, 63KVA Resistance Welder
Request a Quote

63KVA resistance welders are mainly used for the welding of iron, copper plates or wires. With 63KVA power, AC spot welding is capable of welding plates with a thickness of 3+3mm and wires with a diameter of 8+8mm. The arm length of 63KVA resistance welder is 420mm, but can be modified to meet different industry requirements. Because the resistance welding transformer is a key part, and in order to ensure the normal operation of single-phase welding system, Jiaxiao provides replacements for the resistance welding transformer within 5 years. Primary information for the 63KVA resistance welder is shown below. For more information, please contact us directly.

Parameters
Model DTN-63
Rated capacity 63KVA
Rated voltage input 380V/50hz
Max shot-cut current 19KA
Max welding input 132KVA
Duty cycle 15%
Arm dimension 220*420mm
Max.pressing force 3900N
Cylinder stroke 60mm
Consumer of cooling water ≥3.5L/min
Electrode head Φ16mm
Electrode holder Φ25mm
Electrode arm Φ49mm
Projection platform 110*130mm
Max Welding ability 3+3mm
Weight 265kg
Dimension 960*460*1500mm
