3D Elbow
- 30 Degree 3D Elbow
- 45 Degree 3D Elbow
- 60 Degree 3D Elbow
- 90 Degree 3D Elbow
3D Elbow
Ahad is a pipe elbow manufacturer in China. We are an expert in the industrial processes such as bending, pressing, forging, machining etc. Adopting state-of-the –art production equipment, we can manufacture high quality elbows by using reduced raw materials. Due to their high performance and low prices, our pipe elbows are widely used in many industries, such as electricity, petroleum, natural gas, chemicals, shipbuilding, heating, papermaking, metallurgy and so on.
Size
Seamless elbow: 1/2"~24"DN15~DN600
Welding elbow: 6"~60"DN150~DN1500
Wall Thickness
sch10, sch20, sch30, std, sch40, sch60, xs, sch80, sch100,
sch120, sch140, sch160, xxs, sch5s, sch20s, sch40s, sch80s
Max. wall thickness: 200mm
Materials
Carbon steel: ASTM/ASME A234 WPB-WPC
Alloy steel: ASTM/ASME A234 WP 1-WP 12-WP 11-WP 22-WP 5-WP 91-WP 911
Stainless steel: ASTM/ASME A403 WP 304-304L-304H-304LN-304N
ASTM/ASME A403 WP 316-316L-316H-316LN-316N-316Ti
ASTM/ASME A403 WP 321-321H ASTM/ASME A403 WP 347-347H
Low temperature steel: ASTM/ASME A402 WPL 3-WPL 6
High performance steel: ASTM/ASME A860 WPHY 42-46-52-60-65-70
Standards
ASME B16.9-2012, ASME B16.25-2012, ASME B36.10M-2004, ASME B36.19M-2004
MSS SP-75-2008
EN 10253-1-1999, EN 10253-2-2007, EN 10253-3-2008, EN 10253-4-2008
DIN 2605-1-1991, DIN 2605-2-1995
CSA Z245.11-13-2013
SY/T 0609-2006, SY/T 0518-2002
