24mm Size Metal Shaft 6K Rotary Potentiometer, RV24-40S

24mm Size Metal Shaft 6K Rotary Potentiometer, RV24-40S
24mm Size Metal Shaft 6K Rotary Potentiometer, RV24-40S
Request a Quote
About Us: http://gyfasteners.com/4-6-rotary-shaft.html

Part Number

RV24-40S
Dimensions
Parameters
Diameters 24mm
Total rotational angle 300°±10°
Rotational torque 20~200gf.cm
Stopper strength ≥6kgf
Number of resistor elements single-unit
Total resistance 50Ω-2MΩ
Resistance tolerance ±10%
Shaft Types round shaft
Element carbon film
Rated power ≤0.25W
Voltage proof
Operating life ≥10000cycles
Dimensions
